SERVICE MANUAL
18 11NOV05 – SM7648-1
Section 2: Alphabetical Index
Alphabetical Index
Part No. Description Figure No.
3F9124 BACK COVER AY 1
3F9165 BATTERY COMPARTMENT AY 4
3F9158 BOARD - CA1, CCD 4
3F9168 BOARD - CP1, MCU 3
3F9163 BOARD - ST1, capacitor 4
3F9145 BOARD - ST2, strobe position 4
3F9117 BOARD - TB1, shutter and mode dial 3
3F9146 BOARD - TB2, focus and strobe mode 4
3F9138 BOARD - TB3, AC adapter/USB connector 4
3F9115 BOARD - TB4, battery sensor 4
3F9170 BUTTON - 5-way, joystick 3
3F9188 CAP - lens 1
3F9133 COVER - hot shoe 1
3F9108 COVER - side 1
3F9149 COVER - strobe 4
3F9119 COVER - top 3
3F9134 COVER - viewfinder ay 1
3F9187 CUSTOM INSERT - dock 1
3F9125 DOOR - card 1
3F9156 FILTER - optical 4
3F9160 FLEXIBLE CIRCUIT - CP1 to CA1 4
3F9166 FLEXIBLE CIRCUIT - CP1 to TB1 3
3F9139 FLEXIBLE CIRCUIT - CP1 to TB3 4
3F9106 FRONT COVER AY 2
3F6051 FUSE 2.0 A, 32 V 3
3F9185 FUSE 5.0 A, 32 V 3
3F9111 HOLDER - side cover 1
3F9152 LENS - DEC 4
3F9154 LENS AY 4
3F9120 MONITOR LCD AY 2
3F9151 PAF SENSOR - parallax auto focus 4
3F9109 PLATE 1
3F9153 RING - adhesive 4
3F6121 SCREW - PCS, 1.7 x 2.5 2, 3, 4
3F9175 SCREW - PCS, 1.7 x 2.5 2, 4
3F9172 SCREW - PCS, 1.7 x 3.0 1, 2
3F9174 SCREW - PCS, 1.7 x 3.5 1, 4
3F9173 SCREW - PCS, 1.7 x 4.0 1, 2
3F9182 SCREW - STPG, 1.4 x 3.0 4
3F9176 SCREW - STPG, 1.7 x 3.0 1
3F9177 SCREW - STPG, 1.7 x 3.0 2, 4
3F9176 SCREW - STPG, 1.7 x 3.5 2
3F9178 SCREW - STPG, 1.7 x 3.5 3
3F9180 SCREW - STPG, 1.7 x 4.0 1
3F9183 SCREW - STPG, 1.7 x 4.0 4
3F9181 SCREW - STPG, 1.7 x 4.5 3
