Kodak EASYSHARE P850 Service Manual

Illustrated Parts List
SM7648-1 – 11NOV05 17
Figure 4 STROBE, BATTERY COMPARTMENT, and LENS AYs
Item Part No. Description Quantity Notes
1 3F9148 STROBE AY
4 1 Includes:
• 2 SCREWS
• STROBE COVER
• STROBE
2 3F9177 SCREW - STPG, 1.7 x 3.0
4 4
3 3F9149 COVER - strobe
4 1
4 3F9115 BOARD - TB4, battery sensor
4 1
5 3F9165 BATTERY COMPARTMENT AY
4 1
6 3F9178 SCREW - TPG, 1.7 x 3.5
4 1
7 3F9163 BOARD - ST1, capacitor
4 1
8 3F6121 SCREW - PCS, 1.7 x 2.5
4 1
9 3F9146 BOARD - TB2, focus and strobe mode
4 1
10 3F9174 SCREW - PCS, 1.7 x 3.5
4 2
11 3F9158 BOARD - CA1, CCD
4 1
12 3F9183 SCREW - STPG, 1.7 x 4.0
4 2
13 3F9160 FLEXIBLE CIRCUIT - CP1 to CA1
4 1
14 3F9162 SPACER - CA1, flexible
4 1
15 3F9157 SPACER
4 1
16 3F9156 FILTER - optical
4 1
17 3F9155 SPACER - LPF
4 1
18 3F9154 LENS AY
4 1
19 3F9153 RING - adhesive
4 1
20 3F9152 LENS - DEC
4 1
21 3F9175 SCREW - PCS, 1.7 x 2.5
4 3
22 3F9176 SCREW - TPG, 1.7 x 3.5
4 1
23 3F9139 FLEXIBLE CIRCUIT - CP1 to TB3
4 1
24 3F9138 BOARD - TB3, AC adapter/USB connector
4 1
25 3F9142 SPEAKER AY
4 1
26 3F9182 SCREW - STPG, 1.4 x 3.0
4 1
27 3F9145 BOARD - ST2, strobe position
4 1
28 3F9151 PAF SENSOR - parallax auto focus
4 1
