Kodak EASYSHARE P850

SERVICE MANUAL
36 11NOV05 – SM7648-1
LENS - “Lens Adjustment (90 cm)”
Adjustment Specification
Prerequisites:
None
To Check:
You cannot check this adjustment.
Purpose: To measure and store the values for the focus.
Do When: After installing a new:
• CP1 BOARD - MCU
• MONITOR LCD AY
• LENS AY
Specification: The test results must comply with the specification values.
•“AF_WIDE: ZW” focus at zoom position “Wide”
– -50<=ZW<=50
•“AF_MID1: ZM1” focus at zoom position center 1
– -25<=(ZM1-ZW)<=25
•“AF_MID2: ZM2” focus at zoom position center 2
– -35<=(ZM2-ZW)<=35
•“AF_MID3: ZM3” focus at zoom position center 3
– -25<=(ZM3-ZW)<=25
•“AF_MID4: ZM4” focus at zoom position center 4
– -25<=(ZM4-ZW)<=25
•“AF_MID5: ZM5” focus at zoom position center 5
– -30<=(ZM5-ZW)<=30
•“AF_MID6: ZM6” focus at zoom position center 6
– -30<=(ZM6-ZW)<=30
•“AF_TELE: ZT” focus at zoom position “Tele”
– -35<=(ZT-ZW)<=35
Special Tools: • SERVICE SOFTWARE
• Computer
• 5 V AC ADAPTER
• USB CABLE
• TARGET - Siemens star
