Kodak EASYSHARE P850

SERVICE MANUAL
78 11NOV05 – SM7648-1
Upgrading the Firmware Using the MEMORY CARD
Important
When you install a new CP1 BOARD - MCU, the correct version of the firmware file must be installed.
[1] Connect the 5 V AC ADAPTER to the CAMERA.
[2] Energize the CAMERA.
[3] Check that “AUTO...” is selected for the “IMAGE STORAGE”.
[4] De-energize the CAMERA.
[5] Insert:
• MEMORY CARD in a CARD READER
• CARD READER in the computer
[6] Format the MEMORY CARD.
[7] Make a folder in the root directory on the MEMORY CARD with the name “System”.
[8] Obtain the firmware file “KP850nnn.FW” from the https://partner.kodak.com/ Web site.
[9] Make a copy of the new version of the “KP850nnn.FW” file.
[10] Install the “KP850nnn.FW” file into the “System” folder on the MEMORY CARD.
[11] Remove the MEMORY CARD from the computer.
[12] Install the MEMORY CARD into the CAMERA.
Important
Do not select any other mode during the energizing.
[13] Energize the CAMERA.
[14] Check that the CAMERA energizes.
[15] Do the steps that display on the MONITOR LCD using the JOYSTICK to select:
•“Upgrade”
•“Continue”
[16] Check that downloading begins.
[17] Wait until downloading completes.
[18] When the downloading is completed, select either “Delete upgrade file” or “Exit”.
[19] De-energize the CAMERA.
[20] Remove the MEMORY CARD.
[21] Energize the CAMERA.
[22] Check that the firmware on the CAMERA is the correct version.
[23] If either of the following conditions occur, do this procedure again:
• upgrading the firmware was not successful
• 5 V AC ADAPTER is disconnected from the CAMERA during the downloading
