Kodak EASYSHARE P850 Service Manual

SERVICE MANUAL
98 11NOV05 – SM7648-1
TB3 BOARD - AC ADAPTER/USB CONNECTOR
TB3
DC-
DC+
FBMH1608HL300
L6704
AVR-M1608C120MT2AB
VA673
FBMH1608HL300
L6703
BK1608HM102
L6702
1;B
C6701
BK1608LM751
L6701
1AV4J11SJ082G
CN671
HEC3600-017010
DC JACK
JK671
0;1/16Z
R6701
0;1/16Z
R6702
0;1/16Z
R6703
1AV4J11B7431G
CN672
4
VCC
5
VIDEO
6
GND
7
AUDIO
8
AVDET(G)
TO CP1(PWA)
1
GND
2
+D
3
-D
Z1Z2
1
2
3
4
VCC
5
VIDEO
6
GND
7
AUDIO
8
AVDET(G)
1
GND
2
+D
3
-D
Z1 Z2 Z3 Z4
T3-02300/SX823-WKO
TB3 BOARD - AC ADAPTER/USB
CONNECTOR
TO CP1(DMA)MAIN CN103
TO USB/AV
P264_0020EC_
