Kodak EASYSHARE P850 Service Manual

SERVICE MANUAL
4 11NOV05 – SM7648-1
Section 1: Illustrated Parts List
Necessary Materials
Primary Tools:
Description Part No.
ESD MAT Region Provided
TWEEZERS Region Provided
SOLDER REMOVAL TOOL Region Provided
FLASH CAPACITOR DISCHARGE TOOL - resistor minimum, 1.2 kW TL-5336
DIGITAL VOLTMETER TL-4114
LIGHT BOX - Arrowin LBF, 2001 -------
DC POWER SUPPLY - 0 - 12 V, 5.0 A with clip leads, ez or alligator Region Provided
TRIPOD - Bogen, Model 3021s TL-5176
TRIPOD HEAD - Bogen, Model 3047 TL-5206
OPTRONICS PHOTOMETER/DETECTOR - Graseby -------
COLOR TEMPERATURE METER - Gossen Color Pro 3F, or equivalent -------
AIR HOSE - optional Region Provided
Computer:
• Microsoft Windows XP OPERATING SYSTEM
• IBM computer or IBM compatible with a Pentium PROCESSOR, 233 MHz or
higher
• 256 MB RAM minimum recommended
• 200 MB hard disk space
• CD-ROM DRIVE
• USB PORT
• 21-in. color MONITOR
• 24-bit XGA VIDEO CARD
• Color VIDEO MONITOR
Region Provided
FEEDBACK SOFTWARE Region Provided
Kodak LENS CLEANING PAPER Region Provided
Kodak LENS CLEANER 1C8000
COVER CLEANER - Johnson SHINE-UP FURNITURE WAX TL-5182
LAMP - Arrowin LBF, 2001 light box, EVC/FGX, Phillips, 6958 Region Provided
FLASH METER TL-5205
STATION - Weller, soldering, 50 W TL-5412
TIP - soldering iron, standard ST1 TL-5413
TIP - soldering iron, single flat ST5 TL-5414
TIP - soldering iron, conical ST7 TL-5415
SCREWDRIVER - Milwaukee, cordless, with battery and charger, optional TL-5424
HEX ADAPTER - 0.40 mm (0.02 in.) bit, optional TL-5421
BATTERY for a POWER SCREWDRIVER - 2.4 V, optional TL-5422
BIT - power, 00 x 80 mm (3.14 in.), 4 mm (0.15 in.) drive, optional TL-5423
TWEEZERS - special TL-5338

Kodak EASYSHARE P850 Specifications

General

Aspect ratio	4:3
LED backlight	Yes
Display diagonal	8 \
Display brightness	250 cd/m²
Display resolution	800 x 600 pixels
Dimensions (WxDxH)	228 x 25.4 x 170.2 mm
Power requirements	100 - 240 V
Display viewable area (HxV)	162.56 x 121.92 mm
Image formats supported	JPG
Product color	Black
Interface	USB 2.0
USB 2.0 ports quantity	1
Compatible memory cards	MMC, MS Duo, MS PRO, SD, SDHC
Power consumption (standby)	0.7 W
Power consumption (typical)	5.5 W

Weight and Dimensions

Weight	560 g
