Kodak EASYSHARE P850 Service Manual

Illustrated Parts List
SM7648-1 – 11NOV05 5
Special Tools
* This item is provided by the region. If using Microsoft Windows XP and Kodak EasyShare SOFTWARE, Version
5.0, load only the DRIVERS for the CAMERA.
** These files are on the Kodak Partner Web site at https://partner.kodak.com/.
*** See “
Configurations for the CAMERA DOCK” on Page 6.
PAINT - 18% gray, interior, flat Region Provided
Vendor:
RC Shaheen
1400 St. Paul Blvd.
Rochester, NY 14621
Telephone: 585-266-1500
MUR1597
TARGET - 18% gray TL-5845
SCREWDRIVER - Phillips, No. 00 x 40 mm (1.57 in.) TL-5429
SCREWDRIVER - Phillips, No. 000 x 40 mm (1.57 in.) TL-5430
SCREWDRIVER - Phillips, No. 2 x 40 mm (1.57 in.) TL-5431
SCREWDRIVER - Phillips, No. 0 x 50 mm (1.97 in.) TL-5432
GEN 2 CAMERA POST - optional TL-5416
GEN 2 CUSTOM TEXT FIXTURE - optional 5E8164
GEN 2 CAMERA POST FABRICATION DRAWING - optional 5E8161
GEN 2 CUSTOM TEST FIXTURE FABRICATION DRAWING - optional 5E8163
Description Part No.
PATTERN BOX - color viewer VJ8-0190
COLLIMATOR Region Provided
TARGET - Siemens, star TL-5884
TARGET - shift lens adjustment TL-5888
TARGET - up and down adjustment TL-5885
TARGET - parallax adjustment TL-5886
TARGET - distance adjustment TL-5887
CAMERA NEST TL-5866
Kodak Li-Ion RECHARGEABLE DIGITAL CAMERA BATTERY KLIC-5001-
1700 mA-hour
106 4062
Kodak EasyShare CAMERA DOCK SERIES 3 includes the 5 V AC ADAPTER 188 6597
Kodak DOCK ADAPTER KIT D-22*** 175 6824
USB CABLE, Model U-8, 8-pin, for Kodak EasyShare DIGITAL CAMERAS 195 5137
A/V CABLE, Model AV-8, 8-pin, for Kodak EasyShare DIGITAL CAMERAS 811 8390
SERVICE SOFTWARE - “DsCalDi.exe”, “camapi32.dll”, and “PTPApi32.dll” **
Firmware file - “KP850100.FW” **
Kodak EasyShare SOFTWARE - Version 4.0 or higher *
Description Part No.

Kodak EASYSHARE P850 Specifications

General

Aspect ratio	4:3
LED backlight	Yes
Display diagonal	8 \
Display brightness	250 cd/m²
Display resolution	800 x 600 pixels
Dimensions (WxDxH)	228 x 25.4 x 170.2 mm
Power requirements	100 - 240 V
Display viewable area (HxV)	162.56 x 121.92 mm
Image formats supported	JPG
Product color	Black
Interface	USB 2.0
USB 2.0 ports quantity	1
Compatible memory cards	MMC, MS Duo, MS PRO, SD, SDHC
Power consumption (standby)	0.7 W
Power consumption (typical)	5.5 W

Weight and Dimensions

Weight	560 g
