SERVICE MANUAL
70 11NOV05 – SM7648-1
• MICROPHONE
–“RD”
–“BL”
• SPEAKER
–“WT”
–“RD”
• TB3 BOARD - AC ADAPTER/USB CONNECTOR
–“PK”
–“GY”
[2] Disconnect the CONNECTORS:
• CN191
• CN303 from TB2
• CN103
[3] Remove:
• 3 SCREWS A
• 2 SCREWS B
[4] Carefully pull the CP1 BOARD - MCU toward you a small distance.
[5] Remove SOLDER from wires from the BATTERY:
•“GY”
•“PK”
•“WT”
[6] Disconnect the CONNECTORS:
• CN302 from ST2
• CN702
• CN301 from TB1
• CN701
• CN101
• CN951
• CN192
[7] Remove the CP1 BOARD - MCU.
To Install:
[1] Reverse the steps in the removal procedure.
[2] Install:
• FRONT COVER AY
• MONITOR LCD AND VIEWFINDER AYs
• BACK COVER AY
Postrequisites:
None
