SERVICE MANUAL
74 11NOV05 – SM7648-1
• SCREW D
• TB3 BOARD - AC ADAPTER/USB CONNECTOR
• SCREW E
• MICROPHONE AND SPEAKER AY
• SCREW F
• ST2 BOARD - STROBE POSITION
• SCREW G
• PAF AY
To Install:
[1] Reverse the steps in the removal procedure.
[2] Install:
• BATTERY COMPARTMENT AY, TB1 BOARD - SHUTTER AND MODE DIAL, AND ST1 BOARD -
CAPACITOR
• CP1 BOARD - MCU
• “FRONT COVER AY” on Page 68
• “MONITOR LCD AND VIEWFINDER AYs” on Page 67
• “BACK COVER AY” on Page 66
Postrequisites:
None
