CVS-842/852/843 Chapter 4
Operation Manual Installation
100
(3 15/16)
320
(12 5/8)
100
(3 15/16)
100
(315/16)
138
(5 3/8)
Unit in mm (inch)
Figure 4.2 Service space required for CVS-842/843
Display Unit
Fixing screws
(M5 screw, 5 pcs)
Mounting bracket
65(2 9/16)
65 (2 9/16)
Knurled fixing bolt
Washer
147
(5 25/32)
147
(5 25/32)
Unit in mm (inch)
Figure 4.3 Fitting detail of CVS-852
93132692-00 4-3
