Koden CVS-852 - Descriptions of the Menu Functions; Pulse Width (H) (L); Transmission

Chapter 6 CVS-842/852/843
Using the Menu Operation Manual
6.4 Menu list
Menu Sub Menu 1 Sub Menu 2 Parameters
Pulse Width (H) Super Short, Short,
Middle, Long
Pulse Width (L) Super Short, Short,
Middle, Long
Output (H) Normal, Low
Output (L) Normal, Low
Transmission
PRR 1 - 10
Enhance
25､35,45,55,65
Color Tone 1 - 3
Background Color 1 - 9
White Line OFF, 1 - 5
Mix Type A, B, C
Flicker Rejection OFF, ON
Past Image OFF, ON
A Scope OFF, ON
Information Window
（NOTE1）
OFF, ON
Zoom Type BTM, BD, ZOOM, B.Z
Zoom Range 2.5 - 200
User 1
User 2
User 3
Depth Value OFF, Large, Middle, Small
Depth Value Position Bottom, Top
Scale OFF, Single, All
Scale Position Side, Center
Scale Value Large, Small
Time Mark OFF, 10 sec, 1 min
Image Direction , ,
Image Partition ,
Image Swap , / ,
Color Bar Scale OFF, ON
Present Position OFF, L/L, LOP
Boat Speed OFF, kt, km/h, mph
Bearing OFF, ON
Water Temp OFF,
o
C,
o
F
Water Temp Graph OFF, ON
Event Position OFF, ON
Event Distance OFF, ON
Event Direction OFF, ON
Display
(NOTE 1)
The Information Window
is not available in
CVS-843
.
Event Elapsed Time OFF, ON
Auto Range OFF, ON
Automatic
Auto Shift OFF, ON
Time
(NOTE2)
Year, Month, Day, Hour,
Min, Sec
Depth Unit M, J.fm, fm, I.fm, ft
Depth Range Preset
Draft Setting 0.0 to 25.5
Bottom Start 0.0 to 20.0
Bottom Detection Inside Range, Outside
range
System
NOTE:
The date display
(year/month/day/a day of
the week) is not available
in the CVS-843 sounder
screen.
Bottom Detection
Threshold
-80 to +40
A
B
B
A
A
B B A
