Chapter 6 CVS-842/852/843
Using the Menu Operation Manual
6.6.21 Water Temp graph
Turns on or off the water temperature graph. To use
this function, an appropriate water temperature sensor
must be connected to the CVS-842/852/843 sounder.
Vertical Split
Water temperature graph position
Normal
Horizontal Split
Selections: OFF, ON
Initial setting: OFF
Figure 6.14 Available positions of Water Temperature Graph
6.6.22 Event position
Turns on or off the Event position display and selects its unit in latitude/longitude or LOP (Time
Difference). In case the Boat Position is set to OFF, the Event position is displayed in
latitude/longitude.
Selections: ON, OFF
Initial setting: OFF
6.6.23 Event distance
Turns on or off the Event distance display and selects its unit from nm, km, or sm. In case the Boat
Speed is set to OFF, the distance to Event is displayed in nm.
Selections: OFF, ON
Initial setting: OFF
6.6.24 Event direction
Turns on or off the direction of Event to own ship.
Selections: OFF, ON
Initial setting: OFF
6.6.25 Event elapsed time
Turns on or off the time elapsed from Event position.
Selections: OFF, ON
Initial setting: OFF
6.7 Automatic (functions)
There are two auto functions available for range selection or depth shift control:
Selections: Auto Range, Auto Shift
6-14 0093132692-05
