CVS-842/852/843 Chapter 6
Operation Manual Using the Menus
clarity. The rate of sensitivity reduction can be selected from Linear or 8800 (Log) type.
Selections: Linear, 8800 type ﾟ
Initial setting: Standard
6.9.3 Color customize
All colors used on the screen can be customized to your preference. There are 256 color palettes
available in total. Each palette has Red, Green and Blue sub palettes with 256 color tones available.
6.9.4 Panel lock
Disables the functions of controls and keys to avoid deviation of these settings by unintentionally
touching them during operation. This functions is applicable to all controls and keys on the operation
panel.
Initial setting: All OFF
CAUTION: The MENU key and the four way arrow keys cannot be function-locked.
6.9.5 Panel brilliance
Controls the brilliance of the operation panel.
Selections: 1/5 (Brightest) to 5/5 (Darkest)
Initial setting: 5/5
6.10 Initialize
6.10.1 User setting
This sub menu is used to newly register the menu-driven functions specified by the user to internal
registers, named User 1 through to User 4.
CAUTION: When new settings are registered, the previous settings will be deleted.
Record all old settings for possible future use before implementing the above functions.
To register:
(1) Press the up or down arrow key to select User Setting and then select User Setting 1, for
example.
(2) Press the right arrow key to select “Registration” => “Execute” and then press the right arrow key.
The menu display disappears and now user defined menu functions are registered to the User
Setting 1 register.
To delete:
(1) Press the right arrow key to select “Registration” => “Clear” and further press the right arrow key.
The menu display disappears and now user defined menu functions are deleted from the User Setting
1 register.
0093132692-05 6-19
