TracPhone V7-HTS User’s Guide
134
Troubleshooting
Antenna/ACU Status
MTA/RSM(GPRS) Status
Message Description
ANTENNA STATE General status of the antenna; must be
“Tracking” to connect to mini-VSAT
Broadband
ANTENNA DC INPUT DC voltage measured at the antenna’s
circuit board; should be between
38 VDC and 44 VDC
CURRENT AZ/EL Azimuth and elevation at which the
antenna is currently pointing; azimuth
is relative to vessel heading if heading
data is available, or the antenna’s
“Forward” arrow (bow) if heading
data is not available
CURRENT SKEW Current skew angle of the antenna’s
LNB
IPACU DC INPUT DC voltage measured at the ICM’s
power input; should be between
23 VDC and 25 VDC
IPACU ENET MODEM
PORT STATE
Status of the ICM’s Ethernet
connection to its built-in modem;
“Link” indicates the jumper cable is
connected between B1 and B2 on the
ICM’s rear panel
Message Description
MTA STATUS Status of the ICM’s built-in MTA;
“Registered” indicates the MTA is
connected to the voice service
RSM (GPRS) STATUS Status of the antenna’s built-in remote
service and support module (GPRS
modem); “Registered” indicates a
good GPRS cellular connection
