TracPhone V7-HTS User’s Guide
44
Tracking Avoidance Zones
Setting Up Tracking Avoidance Zones
To manually configure a tracking avoidance zone, follow these steps.
1. Identify the necessary azimuth range for the zone (see
“Identify the Azimuth Range” on page 45).
2. Identify the necessary elevation range for the zone (see
“Identify the Elevation Range” on page 46).
3. At the TracPhone V7-HTS web interface, configure a tracking
avoidance zone for that combination of azimuth and elevation
ranges (see “Configure the Tracking Avoidance Zone(s) at the
Web Interface” on page 47).
Important!
KVH actively monitors your antenna system’s performance and will
configure a tracking avoidance zone over the air whenever an obvious
blockage area is identified. Therefore, setting up zones yourself on the
vessel is unnecessary in most cases.
