TracPhone V7-HTS User’s Guide
91
Network Configuration
LAN Settings
By default, the High-speed LAN has a gateway of 192.168.6.1 and
assigns IP addresses in the 192.168.6.50-150 range. If this configuration
conflicts with an existing onboard network, you may change the
settings at the TracPhone V7-HTS web interface (see below). The
Unlimited LAN (gateway 192.168.5.1) cannot be changed; if it conflicts
with an existing network, please contact KVH Technical Support.
NOTE: If the optional CommBox software is enabled, the Network Settings
page of the ICM will not contain any configurable fields.
To change the ICM’s High-speed LAN settings, follow these steps:
1. At the TracPhone V7-HTS web interface, click the Settings tab.
Then click Network Settings.
2. In LAN Settings, click Edit.
3. If the Login window appears, log in with the Administrator
password.
4. Modify the IP Address, Subnet Mask, and DHCP Mode
settings as necessary.
5. Click Save.
6. At the confirmation message, click Save.
Figure 7-22 LAN Settings
Important!
The default LAN settings work well for most installations. Do not
change these settings unless absolutely necessary.
