TracPhone V7-HTS User’s Guide
19
Getting Started
Understanding the Home Page
The Home page of the TracPhone V7-HTS web interface provides
essential system status information, including the status of the
antenna, the system’s connection to the mini-VSAT Broadband service,
and the voice service connection. It also displays the vessel’s GPS
position and true heading and provides a graphical representation of
the antenna’s pointing direction relative to the bow of the vessel.
Figure 2-3 Real-time Vessel & VSAT Satellite Display
Important!
If true heading is not displayed, the TracPhone system does not have a
valid connection to the vessel’s NMEA 0183 talker.
Tr ue Heading
GPS Position
Antenna Pointing
Direction
