TracPhone V7-HTS User’s Guide
94
Network Configuration
CommBox Settings
If the optional CommBox software is enabled, the ICM’s network
settings are configured by KVH over the air. The Network Settings
page of the ICM and mini-VSAT Manager will not contain any
configurable fields.
NOTE: See “CommBox Features” on page 106 for details on enabling the
CommBox software.
For complete details about the CommBox software, refer to the
CommBox manual. To view the CommBox manual, follow these steps:
1. At the TracPhone V7-HTS web interface, click the CommBox
tab.
Figure 7-25 CommBox Tab
2. Click Log in to CommBox Control.
3. Log into the CommBox web page with your CommBox user
name and password.
NOTE: The CommBox user name and password differs from the ICM’s
Administrator password.
4. At the CommBox web page, click the Help tab.
Figure 7-26 CommBox Help Tab
