TracPhone V7-HTS User’s Guide
167
Specifications
System Specifications
Antenna Specifications
* Specifications are subject to change without notice.
Attribute Rating
Meets Inmarsat operational, survival, and shock specifications
RX receive/TX transmit
frequency band
10.95-12.75 GHz/14.0-14.5 GHz
Antenna gain 35.6 dBi (RX-band, min)
Transmit power (BUC) 4 W max
Elevation range -24° to +119° (with heading input)
Azimuth range 710° rotation
Satellite coverage See www.kvh.com/minivsatmap
Temperature Operational: -22° F to +131° F (-30° C to +55° C)
Survival: -22° F to +158° F (-30° C to +70° C)
Humidity IEC 60945; 104° F (40° C), 95% humidity (non-
condensing)
Rain 100-knot wind with 1.7 mm/min (4"/hr) rain, with
droplet size between 0.5 and 4.5 mm
Outside dimensions 26.2" (66.6 cm) OD x 31.2" (79.2 cm) H
Weight 57.6 lbs (26.1 kg)
