TracPhone V7-HTS User’s Guide
159
Wiring Diagram
Wiring Diagram
The wiring diagram below shows the basic system connections. For detailed installation
instructions, refer to the Installation Guide.
B2
Power
43 VDC
Common
Port 1, TxD+ Port 1, TxD-
Port 1, RxD+
Port 2, TxD+
Port 1, RxD-
Port 2, TxD-
Port 2, RxD+ Port 2, RxD-
GPRS, TxD+ GPRS, TxD-
GPRS, RxD+ GPRS, RxD-
N/C
N/C
Antenna
MTx
MRx
ICM
White/Orange
Orange/White
White/Brown
Green/White
White/Green
Blue/White
White/Blue
Brown/White
Orange/Red
Red/Orange
Terminal
Strip
Connectors
NMEA 0183 Talker
(customer-supplied)
Power/
Data
TxRF
RxRF
AB
Red
Black
White/Gray
Gray/White
Ground
Two unused wires are reserved for future use; N/C = Not Connected
B2
B1
12 1110987612543 13 14 15 16
12
To Antenna NMEA
Vessel PCVessel Phone
Drain
Wire
Ship’s Heading
User
Ethernet 1
Voice
Line 1
GPS position can
also be provided.
