TracPhone V7-HTS User’s Guide
80
Network Configuration
8. To enable the ICM’s built-in wireless access point (WAP) for
Wi-Fi access, follow the steps in “Wireless Settings” on
page 83.
9. Make sure all non-static IP computers are configured for
DHCP addressing (see “Configuring Computers for DHCP” on
page 85). Devices connected to “User Ethernet” ports 1-3 and
Wi-Fi will receive IP addresses from the ICM via DHCP. The
ICM serves as a router.
10. Set up user names and passwords and allocate data for each
High-speed LAN user at the mini-VSAT Manager
(www.mykvh.com). Go to the Terminal > Data Plan section of
the Vessel Details page and select Data Allocation.
Figure 7-11 Data Allocation: Users (Example)
Figure 7-12 Data Allocation: Allocation Profiles (Example)
NOTE: By default, the High-speed LAN has a gateway of 192.168.6.1 and
assigns IP addresses in the 192.168.6.50-150 range. If this configuration
conflicts with an existing onboard network, you may change the settings at
the TracPhone V7-HTS web interface (go to Settings > Network Settings).
See “LAN Settings” on page 91 for details. The Unlimited LAN (gateway
192.168.5.1) cannot be changed at the web interface. If it conflicts with an
existing network, please contact KVH Technical Support for assistance.
