9. DRIVE AND DRIVEN PULLEYS
9-14
MX’er SYSTEM
Install the left crankcase cover and tighten the
cover bolts diagonally.
Connect the drive belt air tube and tighten the
band screw.
Left Crankcase Cove
r
Screw
