6. ENGINE REMOVAL/INSTALLATION
6-3
MX’er SYSTEM
Disconnect the spark plug high-tension
wire.
Remove the spark plug cap and disconnect
the ignition coil wire from the set plate.
Remove the rear drive chain gear on the
bolts.
Remove the drive chain gear.
Remove the two bolts and two joint lock
nuts attaching the exhaust muffler.
Remove the exhaust muffler.
ENGINE REMOVAL
Remove the engine any connector thing.
Remove the engine back bracket tow bolts.
Ignition Coil Wire
Drive Chain Gea
To Next Page
