6. ENGINE REMOVAL/INSTALLATION
6-4
MX’er SYSTEM
Remove the engine front bracket bolt.
ENGINE HANGER BRACKET
REMOVE
Remove the two bolts on the left engine
hanger bracket.
Remove the left engine hanger bracket.
Remove the engine.
ENGINE INSTALLATION
Install the engine and tighten the engine
mounting bolts.
Torque: 3.54.5kgf-m
Install the removed parts in the reverse
order of removal.
Bol
t
Engine Hanger Bracke
t
Bolts
Route the wires and cables properly.

