Kyocera FS-1920 User Manual

2FP/2FY/2FR
2-3-9
Connector Pin No. Signal I/O Voltage Description
CN1
Connected
to the AC
inlet
CN2
Connected
to the
heater lamp
YC901
Connected
to the
engine
board
YC902
Connected
to the fuser
board
1 LIVE I 120 V AC AC power supply
220 - 240 V AC
2 GND - - Ground
3 NEUTRAL I 120 V AC AC power supply
220 - 240 V AC
1 LIVE O 120 V AC Power supply for heater lamp
220 - 240 V AC
2 NEUTRAL O 120 V AC Power supply for heater lamp
220 - 240 V AC
1 +24V3 I 24 V DC 24 V DC power supply
2 FDPFUL* O 0/5 V DC Paper full sensor: On/Off
3 FUDR I 0/24 V DC Face up/down solenoid (UP): On/Off
4 FDDR I 0/24 V DC Face up/down solenoid (DOWN): On/Off
5 THERM O Analog Thermistor detection voltage
6 EXITPAP* O 0/5 V DC Exit sensor: On/Off
7 +5V1 O 5 V DC 5 V DC power supply
8 GND - Ground Ground
9 +24V3 I 24 V DC 24 V DC power supply
10 SLEEP - - Not used
11 ZCROSS O 0/5 V DC (pulse) Zero cross signal
12 HEATON* I 0/24 V DC Heater lamp: On/Off
13 +5V1 O 5 V DC 5 V DC power supply
14 +5V1 O 5 V DC 5 V DC power supply
15 +5V1 O 5 V DC 5 V DC power supply
16 +5V1 O 5 V DC 5 V DC power supply
17 GND - Ground Ground
18 GND - Ground Ground
19 GND - Ground Ground
20 GND - Ground Ground
21 +24V1 O 24 V DC 24 V DC power supply
22 +24V1 O 24 V DC 24 V DC power supply
23 +24V1 O 24 V DC 24 V DC power supply
24 +24V1 O 24 V DC 24 V DC power supply
1 +5V1 O 5 V DC 5 V DC power supply
2 GND - Ground Ground
3 THERM I Analog Thermistor detection voltage
4 EXITPAP* I 0/5 V DC Exit sensor: On/Off
5 FDDR O 0/24 V DC Face up/down solenoid (DOWN): On/Off
6 FUDR O 0/24 V DC Face up/down solenoid (UP): On/Off
7 +24V3 O 24 V DC 24 V DC power supply
8 FDPFUL* I 0/5 V DC Paper full sensor: On/Off

Kyocera FS-1920 Specifications

General

Print Technology	Laser
Resolution	600 x 600 dpi
Warm-up Time	15 seconds
Time to First Page	9 seconds
Processor Frequency	200 MHz
Type	Monochrome Laser Printer
Supported Operating Systems	Windows, Mac OS, Linux
Connectivity	USB 2.0
Memory	32 MB
Output Capacity	250 sheets
