Kyocera Mita FS-1128MFP Service Manual

2JN-2
1-3-7
U000
Event log
Detail of event log
Maintenance
item No.
Description
Firmware version 2JN_2F00.001.177
Paper Jam Log
Counter Log
2009.04.06
J10:000
J11:000
J12:000
J20:002
J21:000
J22:000
J30:000
J31:000
J73:000
J74:000
J78:000
C0100:001
C0110:001
C0120:001
C0150:001
C0170:001
C0420:001
C2000:001
C2610:001
C2620:001
M00:01
#
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
Count.
9876543
666554
4988
4988
4988
4988
1103
1103
1103
1103
1027
1027
1027
1027
550
28
Event
Descriprions
10.01.08.01.01
10.01.08.01.02
10.01.08.01.01
10.01.08.01.02
10.01.08.01.01
10.01.08.01.02
10.01.08.01.01
10.01.08.01.01
12.03.08.01.01
12.03.08.01.01
12.03.08.01.01
12.03.0A.01.01
12.03.08.01.01
12.03.08.01.02
12.03.0A.01.01
12.03.08.01.01
Service Call Log
#
8
7
6
5
4
3
2
1
Count.
7881214
578944
5296
5295
2099
1054
809
30
Service Code
01.0060
01.0120
01.4000
01.3100
01.2000
01.2000
01.2200
01.2500
Maintenance Log
#
8
7
6
5
4
3
2
1
Count.
9045571
704511
7045
3454
3454
3454
417
35
Item
01.00
02.00
01.00
02.00
01.00
02.00
01.00
02.00
Unknown toner Log
#
5
4
3
2
1
Count.
3454
3454
3454
417
35
Item
01.00
01.00
01.00
01.00
01.00
Event Log
MFP
(f) (g) (h)
(a) (b) (c) (d) (e)
10. 01. 08. 01. 01
(1)
(3)
(7)
(4)
(5)
(6)
(2)
No. Items Description
(1) System version
(2) System date
(3) Paper Jam Log # Count. Event
Remembers 1 to 16 of
occurrence. If the
occurrence of the previ-
ous paper jam is less
than 16, all of the paper
jams are logged. When
the occurrence
excesseds 16, the old-
est occurrence is
removed.
The total page count at
the time of the paper
jam.
Log code (2 digit, hexa-
decimal, 5 categories)
(a) Cause of a paper
jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper eject
