Kyocera Mita FS-1128MFP Service Manual

2JN
1-3-57
U633
Setting communication control 4
Description
Makes settings for fax transmission regarding the communication.
Purpose
To reduce transmission errors when a low quality line is used.
Start
1. Press the start key.
2. Select the item to be set using the cursor up/down keys.
Enabling/disabling V.34 communication
Sets whether V.34 communication is enabled/disabled for transmission and reception.
1. Select the setting using the cursor up/down keys.
Initial setting: ON
2. Press the start key. The setting is set.
Setting the V.34 symbol speed (3429 Hz)
Sets if the V.34 symbol speed 3429 Hz is used.
1. Select the setting using the cursor up/down keys.
Initial setting: ON
2. Press the start key. The setting is set.
Setting the number of times of DIS signal reception
Sets the number of times to receive the DIS signal to once or twice. Used as one of the correction measures
for transmission errors and other problems.
1. Select the setting using the cursor up/down keys.
Initial setting: ONCE
2. Press the start key. The setting is set.
Maintenance
item No.
Description
Display Description
V.34 Enables or disables V.34 communication.
V.34-3429Hz Sets the V.34 symbol speed (3429 Hz).
DIS 2RES Sets the number of times of DIS signal reception.
RTN CHECK Sets the reference for RTN signal output.
Display Description
ON V.34 communication is enabled for both transmission and reception.
TX V.34 communication is enabled for transmission only.
RX V.34 communication is enabled for reception only.
OFF V.34 communication is disabled for both transmission and reception.
Display Description
ON V.34 communication is enabled for both transmission and reception.
TX V.34 communication is enabled for transmission only.
RX V.34 communication is enabled for reception only.
OFF V.34 communication is disabled for both transmission and reception.
Display Description
ON V.34 symbol speed 3429 Hz is used.
OFF V.34 symbol speed 3429 Hz is not used.
Display Description
ONCE Responds to the first signal.
TWICE Responds to the second signal.
