2JN
1-3-14
U034
Adjustment: Center line adjustment
1. Select the item to be adjusted using the cursor up/down keys.
*: Setting the difference value from reference value
2. Press the system menu/counter key.
3. Press the start key to output a test pattern.
4. Press the system menu/counter key.
5. Change the setting value using the cursor left/right keys or numeric keys.
For output example 1, decrease the value. For output example 2, increase the value.
Figure 1-3-2
6. Press the start key. The value is set.
Caution
Check the copy image after the adjustment. If the image is still incorrect, perform the following adjustments in
maintenance mode.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description Setting
range
Initial
setting
Change in
value per step
LEFT Adjustment of reference value 0 to 1180 235 0.04 mm
MP TRAY Paper feed from MP tray* -70 to 70 0 0.04 mm
CASSETTE 1 Paper feed from cassette 1* -70 to 70 0 0.04 mm
CASSETTE 2 Paper feed from optional cassette 2* -70 to 70 0 0.04 mm
CASSETTE 3 Paper feed from optional cassette 3* -70 to 70 0 0.04 mm
DUPLEX Duplex mode (second side)* -70 to 70 0 0.04 mm
Center line of printing
Correct image Output
example 1
Output
example 2
U034
U067
(P.1-3-20)
U072
(P.1-3-25)
To Next Page
