LaCie Ethernet Disk RAIDNetwork RAID Storage System - Enabling Remote Boot

LaCie Ethernet Disk RAID (Firmware version 1.4)
User Manual
page 103
Protecting Local Disks
7.8.1. Enabling Remote Boot■
To enable remote boot:
In the Protected disk list on any page, select your
system disk or partition. If you protected multiple
system disks or partitions, select the first system disk
or partition on your computer (typically Disk 0).
From the Action menu, click Enable Remote Boot.
e Enable Remote Boot dialog box appears (see
Fig. 7.8.1.A.). is dialog box displays a list of all the
NICs on your computer.
From the list, select the NIC that you want to use
when remotely booting from the Ethernet Disk
RAID.
1.
2.
3.
Fig. 7.8.1.A
Click Enable. A message appears, advising you that
your network connection will be temporarily inter-
rupted.
Click Yes to allow the temporary network inter-
ruption. (Your network connection will be re-
stored immediately after this process is complete.)
On the Enable Remote Boot dialog box, the Details
area shows the progress of the enabling process. If
any problems are encountered – for example, if the
selected disk or partition was not your system disk
– that portion of the process is marked as “Failed.”
You can click the plus sign next to the process de-
scription to expand it and display an error message
that explains exactly what happened.
4.
5.
Fig. 7.8.1.B
