14 Appendix
Technical Data AK05-51 Used for UL Listed Section and hazardous area Class I Division 2
Protection class: TC-ER (Tray Cable Exposed Run), outdoor
Housing material: Outer sheath of special PVC
Minimum bending radius: Static/Occ. moved: 6/20 x OD (Outer diameter)
Temperature range: Static/Occ. moved: -40/-10 °C ... +90 °C / -40/+14 °F ... +194 °F
Cross-section: 14 × 0,9 mm
2
/ 18 AWG
Shild: copper braiding
Core identification: black cores with continuous white numbering
