105
14 Appendix
1
The product must not be operated outside the specified range. If it is, any guarantees with regard to safety-related functions lose
their validity.
2
If the critical load is exceeded (e.g. as a result of a contactor load), the specified minimum value is no longer guaranteed. The min-
imum value is important for PLC-type applications.
14.1.3.2 FN30 power supply
NOTICE
The power supply unit FN30 can only be used to operate the F300K on an AC mains voltage
within the scope of EN 60950 or UL 60950.
The FN30-00 (MEAN WELL Model DR-30-24) is UL Recognized approofed.
Ambient temperature:
1
- 20 … + 60 °C
Humidity Relative humidity of 20 ... 90% RH, non-condensing
Storage/transport conditions
Storage location: Enclosed spaces
Air temperature:
1
- 40 … + 70 °C/-40 ... +158 °F
Humidity: 90% relative humidity at 25 °C, non-condensing
Weight: 0.35 kg/0,77 lb
Climatic range
Details of the FN30-00 IP20
Fig. 14-9 Dimension drawing front
Fig. 14-10 Dimension drawing side
