14 Appendix
14.1.3 Power Pack
14.1.3.1 FN20, FN30-20 Power Supply
NOTICE
The FN20 (115 V) is UL Listed approofed.
WARNING!
Instalation
The wires must be installed/attached in such a way that, if a wire is unintentionally loosened,
a sufficient distance is still maintained between SELV/PELV and the other voltages.
Width: 77 mm/3,03" in
Length: 90 mm/3,54" in
Height: 46 mm/1,81"inch from the upper edge of
the top-hat rail
Weight: 0.35 kg/0,77 lb
Fig. 14-5 Dimensions FN 20
