4 Design and Functions
4 Design and Functions
4.1 Design
Structure:
The compact flame scanner consists of a cylindrical housing with an axial aperture and an
LED status display at the back or an integrated operating unit with an UI (user interface).
Connection:
The connection is made via the serial connector on the F300K and the required connecting
cable (14-pin with static shielding) with coupling.
The cable offers the following connections:
• Supply of auxiliary power
• Flame contact
• Ready contact
• Measuring output for intensity
• FSB (Bus)
• Shield
