14.1.6 Flame Scanner Testing Device

Fig. 14-27 Dimensioned drawing of the FB30

Fig. 14-25 Flame Scanner Testing Device FFP30

Fig. 14-26 1. (1) Positions of the internal jumper IR + UV

A, B, C Threaded receptacle for F200K, F300K

Plug-in receptacle for FFS05, FFS06, FFS07, FFS08, F200K

D Changing battery (9 V, 500 mA - turn left to open housing)

E Toggle switch
