72
7 Operation
7.5.5.2 Device parameters load (up load)
The device parameters saved to the operating unit are loaded in the flame scanner.
NOTICE
The current settings of the flame scanner are lost when the device parameters are reset.
Resetting device parameters
Selected device parameters
Data Line 1 - loaded from user interface (UI)
Data Line 2 - received from the flame scan-
ner
The data in line 1 must match the data in
line 2.
The transfer was successful.
