3 Product Description

3.7.6 FG30 connection housing

Regard the applicable rules and regulations for mounting and installation, note also the addi-

tional requirements described in section 6.1.1 Safety When Putting the Device Into Operation

LAMTEC offers two versions of the FG30 connection housing:

• FG30-00 with cable glands and an M12 circular connector for FSB

• FG30-20 Ex-II for use in potentially explosive atmospheres with cable glands and an M12

circular connector for FSB

You will find technical specifications for the housings in section 14.1.4 FG30 connection hous-

ing and FG30-21 stainless steel.

Fig. 3-11 FG30-00 connection housing

Fig. 3-12 FG30-20 Ex-II connection housing
