ECO GOLD
68 Technical data and graphs 25/08/2011/ YACE0088
Immersion thermostats
ECO GOLD
230 V 220 V 115 V 100 V
Working temperature range °C 20…200
Working temperature range with water
cooling
°C 20…200
Operating temperature range °C -20…200
Heater rating / power consumption kW 2.6/2.7 2.4/2.5 1.3/1.4 1/1.1
Heater surface loading W/cm² 6.8 6.2 6.8 5.1
Bath depth mm At least 150
Overall dimensions
(W x D x H)
mm 130 x 135 x 325
Weight kg 3.4 3.4 3 3
Mains connection Catalogue number
230 V ±10 %; 50/60 Hz LCE 0228 --- --- ---
220 V ±10 %; 60 Hz --- LCE 2228 --- ---
115 V ±10 %; 60 Hz --- --- LCE 4228 ---
100 V ±10 %; 50/60 Hz --- --- --- LCE 6228
at Pump power level 1
with extraneous cooling
