Heating thermostats with stainless steel bath
E 4 G E 10 G E 15 G E 20 G E 25 G E 40 G
Working temperature range { °C 20…200
Working temperature range with water
cooling
°C 20…200
Operating temperature range | °C -20…200
Temperature accuracy K ±0,01
Bath volume L 3…3.5 7.5…11 12…16 13…19 16…25 32…40
Bath vessels
Inner tank in deep-drawn stainless steel 1.4301 conforming to
SAE 30304 AISI 304
Outer jacket Powder-coated steel sheet
Bath opening (B x T) mm 135 x 105 300 x 190 300 x 190 300 x 365 300 x 365 613 x 300
Bath depth mm 150 150 200 150 200 200
Usable bath depth mm 130 130 180 130 180 180
Height of bath edge without cover mm 196 196 246 196 246 248
Overall dimensions (W x D) mm 168 x 272 331 x 361 331 x 361 331 x 537 331 x 537 350 x 803
Overall height mm 376 376 426 376 426 428
Pump connection
Stainless steel fittings 13 mm (thread
M16 x 1)
Standard  Optional accessory
230 V; 50/60 Hz
Heater rating / power consumption kW 2.6/2.7
Weight kg 7.0 9.0 10.7 12.2 13.5 17.6
220 V; 60 Hz
Heater rating / power consumption kW 2.4/2.5
Weight kg 7.0 9.0 10.7 12.2 13.5 17.6
115 V; 60 Hz
Heater rating / power consumption kW 1.3/1.4
Weight kg 6.6 8.6 10.3 11.8 13.1 17.2
100 V; 50/60 Hz
Heater rating / power consumption kW 1/1.1
Weight kg 6.6 8.6 10.3 11.8 13.1 17.2
Mains connection Catalogue number
E 4 G
E 10 G E 15 G E 20 G E 25 G E 40 G
230 V ±10 %; 50/60 Hz
LCB 0737
LCB 0739 LCB 0741 LCB 0743 LCB 0745 LCB 0747
220 V ±10 %; 60 Hz
LCB 2737
LCB 2739 LCB 2741 LCB 2743 LCB 2745 LCB 2747
115 V ±10 %; 60 Hz
LCB 4737
LCB 4739 LCB 4741 LCB 4743 LCB 4745 LCB 4747
100 V ±10 %; 50/60 Hz
LCB 6737
LCB 6739 LCB 6741 LCB 6743 LCB 6745 LCB 6747
 at Pump power level 1  with extraneous cooling  Optional accessory
