Lauda E 4 G - Heating thermostats with transparent bath

ECO GOLD
70 Technical data and graphs 25/08/2011/ YACE0088
Heating thermostats with transparent bath
ET 6 G ET 12 G ET 15 G ET 20 G
Working temperature range { °C 20…100
Working temperature range with water cool-
ing
°C 20…100
Operating temperature range | °C -20…100
Temperature accuracy K ±0,01
Bath volume L 5…6 9.5…12 13.5…15 15…20
Bath vessels Polycarbonate
Usable bath opening (W x D) with control
head
mm 130 x 285
300 x 175 275 x 130 300 x 350
Bath depth mm 160 160 310 160
Usable bath depth mm 140 140 290 140
Height of bath edge without cover mm 169 208 356 208
Overall dimensions (W x D) mm 143 x 433 322 x 331 428 x 148 322 x 506
Overall height mm 349 389 532 389
Pump connection
Stainless steel fittings 13 mm
(thread M16 x 1)
 Optional
accessory
 Optional
accessory
Standard
 Optional
accessory
230 V; 50/60 Hz
Heater rating / power consumption kW 2.6/2.7
Weight kg 4.5 6.8 6.8 8.0
220 V; 60 Hz
Heater rating / power consumption kW 2.4/2.5
Weight kg 4.5 6.8 6.8 8.0
115 V; 60 Hz
Heater rating / power consumption kW 1.3/1.4
Weight kg 4.1 6.4 6.4 7.6
100 V; 50/60 Hz
Heater rating / power consumption kW 1/1.1
Weight kg 4.1 6.4 6.4 7.6
Mains connection Catalogue number
ET 6 G ET 12 G ET 15 G ET 20 G
230 V ±10 %; 50/60 Hz LCM 0097 LCD 0287 LCD 0289 LCD 0291
220 V ±10 %; 60 Hz LCM 2097 LCD 2287 LCD 2289 LCD 2291
115 V ±10 %; 60 Hz LCM 4097 LCD 4287 LCD 4289 LCD 4291
100 V ±10 %; 50/60 Hz LCM 6097 LCD 6287 LCD 6289 LCD 6291
 at Pump power level 1  with extraneous cooling  Optional accessory
