WaveAce Series
71
WA-GSM-E RevB
The default settings made to the oscilloscope are detailed as follows:
Menu
Option
Default
CH1/CH2
Coupling
DC
BW Limit
Off
Volts/div adjust
Coarse (fixed)
Probe
1X
Invert
Off
Volts/div
1.00V
Menu
Option
Default
MATH
Operation
CH1-CH2
CH1 Invert
Off
CH2 Invert
Off
FFT Operation
Source
CH1
Window
Hanning
FFT Zoom
1X
Scale
dBVrms

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LeCroy WaveAce series and is the answer not in the manual?

LeCroy WaveAce series Specifications

General IconGeneral
Channels2 or 4
Vertical Resolution8-bit
Input CouplingAC, DC, GND
Power Supply100-240 VAC, 50/60 Hz
Sample Rate2 GS/s
Display800 x 480
Input Impedance1 MΩ
Timebase Range5 ns/div to 50 s/div
Trigger TypesEdge, Pulse Width, Video, Slope
ConnectivityUSB host, USB device
