Print Setup
PLEASE NOTE THE FOLLOWING:
 After using an option button to select either the Do Self Test, and
Print Setup (when enabled) functions, more options are then
shown. You can return to the original menu by pressing the UTILITY
front panel button.
 Only when the Back USB option button (covered in the next step) is
set to Printer is the Print Setup option button enabled for use.
 Your printer may override these setup selections to ensure the best
fit. If selections are not supported by your printer, the oscilloscope
uses the Default setting.
 Most USB printers supporting direct printing through Type A USB
port connections are compatible with your WaveAce oscilloscope.
Refer to your printer's product documentation to verify
compatibility.
Print - Page 1/2
After pressing the enabled Print Setup option button, the first of two
PRINT menus (Page 1/2) is shown and contains the following option button
functions.
 Ink Saver - Turn this function On/Off to help save ink on your
printer connected to the back of your instrument.
 Layout - Choose from Portrait or Landscape print layouts as desired.
 Paper Size - Choose from Default, L, 2L, Hagaki Postcard, Card Size,
10 x 15cm, 4" x 6", 8" x 10", Letter, 11" x 17", A0-9, B0-9, 89mm
Roll(L), 127mm Roll(2L), 100mm Roll(4"), and 210mm Roll(A4).
 Print Key - Select whether a picture is saved to a USB memory
device or printed when the PRINT menu control button is pressed.
 Next Page - Use this option button to show Page 2/2.

LeCroy WaveAce series Specifications

General

Channels	2 or 4
Vertical Resolution	8-bit
Input Coupling	AC, DC, GND
Power Supply	100-240 VAC, 50/60 Hz
Sample Rate	2 GS/s
Display	800 x 480
Input Impedance	1 MΩ
Timebase Range	5 ns/div to 50 s/div
Trigger Types	Edge, Pulse Width, Video, Slope
Connectivity	USB host, USB device
