LeCroy WaveAce series User Manual

WaveAce Series
73
WA-GSM-E RevB
Menu
Option
Default
DISPLAY
Type
Vectors
Persist
Off
Grid
Menu Display
Infinite
Menu
Option
Default
REF
Type
Waveform
Source
CH1
Menu
Option
Default
TRIGGER (Edge)
Type
Edge
Source
CH1
Slope
Rising
Mode
Auto
Coupling
DC
Level
0.00V
Menu
Option
Default
TRIGGER (Pulse)
Type
Pulse
Source
CH1
When
=
Set Pulse Width
1.00ms
Mode
Auto
Coupling
DC

LeCroy WaveAce series Specifications

General

Channels	2 or 4
Vertical Resolution	8-bit
Input Coupling	AC, DC, GND
Power Supply	100-240 VAC, 50/60 Hz
Sample Rate	2 GS/s
Display	800 x 480
Input Impedance	1 MΩ
Timebase Range	5 ns/div to 50 s/div
Trigger Types	Edge, Pulse Width, Video, Slope
Connectivity	USB host, USB device
