5. OPERATION - OBJECTIVES
Immersion objectives
t'PSimmersion objectives use the appropriate immersion
medium.
OIL: Use optical immersion oil in accordance with DIN/
ISO standards
only
Cleaning oS. 89
W: Water immersion
IMM: Universal objective for water, glycerin,
Oil immersion
Caution!
Follow safety data sheet for immersion oil!
t4FMFDUBOJNNFSTJPOPCKFDUJWF
The objective nosepiece is lowered to the lower thres-
hold. This makes it possible to apply the immersion fluid
when switching from the dry objective to the immersion
objective. Conversely, the immersion fluid can be re-
moved.
The current objective remains in the beam path.
t1SFTTUIFLFZGPSUIFEFTJSFEJNNFSTJPOPCKFDUJWFXIJDI
is now approached.
Note:
For lockable immersion objectives, press the front part
upwards as far as it will go (approx. 2 mm). Then, after a
gentle turning motion to the right, the objective is locked.
For objectives with a correction mount, adapt the objec-
tive to the thickness of the cover slip by turning the knurled
knob.
Note:
If objectives are retrofitted, they have to be taught in using
the LAS X software: Afterwards, the parfocality should also
be taught in again.
See the instructions for the LAS X.
48
