5. OPERATION - TRANSMIT TED LIGHT CONTR AST ME THOD
t*OTFSUBTQFDJNFO
t'PDVTUIFJNBHFVTJOHUIFGPDVTEJBMT
t$POmHVSFUIFCSJHIUOFTTPOUIFJOUFOTJUZSPUBSZLOPC
Fine adjustment:
For a tiltable Transmitted Light arm:
t5IFmOFBEKVTUNFOUJTNBEFVTJOHUIFLOVSMFETDSFX
on the IMC modulator and the polarizer.
t6TJOHUIFTMJEFSZPVDBOBMTPPGGTFUUIFIFJHIUUPBE-
just the slit diaphragms to the focal plane. This setting
depends on the specimen being observed.
Note:
The position of the polarizer influences the appearance of
the relief. The best relief images are obtained in the extinc-
tion position; the relief disappears at a 90° position.
For a fixed Transmitted Light arm:
IMC module for fixed Transmitted Light arm
t5IF fine adjustment occurs via the knurled screw on
the IMC modulator.
Note:
For adjusting the aperture diaphragms, refer to the Installa-
tion Manual.
IMC module for tiltable Transmitted Light arm
