5. OPERATION - FLUORESCENCE
Leica DMi8 with motorized Transmitted Light method
t$BVUJPO'PSUIF*OUFHSBUFE.PEVMBUJPO$POUSBTUmSTUFO-
able the DIC button!
The correct slit diaphragm is configured and the polarizer
is automatically swung inwards on the motorized con-
denser.
t*OTFSUBTQFDJNFO
t4FMFDUBTVJUBCMFPCKFDUJWFJOUIFNBHOJmDBUJPONFOV
(eyepoint B or C).
t*GOFDFTTBSZSFNPWFUIFDPWFSPGUIFIPMEFSBOEJOTFSU
the IMC module evenly from the front on the left side of
the microscope.
t4MJEFUIF*.$NPEVMFJOUPUIFDPSSFDUeyepoint B or C.
t'PDVTUIFJNBHFVTJOHUIFSPUBSZLOPCPOUIF-FJDB
SmartMove or using the focus dial.
t$POmHVSFUIFCSJHIUOFTTPOUIFJOUFOTJUZSPUBSZLOPC
t5IFfine adjustment is made using the knurled screw (5)
and the polarizer.
Note:
The position of the polarizer influences the appearance of
the relief. The best relief images are obtained in the extinc-
tion position; the relief disappears at a 90° position.
t6TJOHUIFTMJEFSZPVDBOBMTPPGGTFUUIFIFJHIUUPBE-
just the slit diaphragms to the focal plane. This setting de-
pends on the specimen being observed.
Note:
For adjusting the aperture diaphragms, refer to the Installa-
tion Manual.
IMC module for tiltable Transmitted Light arm
1 Position for objectives with eyepoint C
2 Position for objectives with eyepoint B
3 Brightfield position
4 Height adjustment
5 Fine adjustment
1
2
3
4
5
