LELY ASTRONAUT A3 - Feed Funnel

7-14 Preventive Maintenance
D-H001.0609EN
7.11 Feed funnel
1. Take the milking robot out of operation with the X-link (page 6-5).
2. Select:
- Tab [
Test]
- [Box]
- [Gates].
3. In the field Gates, select Exit gate, [
Open].
4. Go into the box via the exit gate.
5. Remove:
- The locking pins (2) on the cover plate of the feed funnel
- The feed funnel cover (1).
6. Make sure:
- The deflector funnel is clean
- The pneumatic feed cylinder is installed correctly and cannot be removed.
CAUTION
Do not touch or put your fingers near the moving parts.
7. Empty the feed bin.
8. Install:
- The feed funnel cover (1)
- The locking pins (2) on the cover plate of the feed funnel.
9. Go out of the box via the exit gate.
10. Select:
- Tab [
Test]
- [Box]
- [Gates].
11. In the field Gates, select, Exit gate, [
Close].
12. Put the milking robot in operation with the X-link (page 6-3).
