- Check all bolts and nuts for tightness.
Pay particular attention to the bolts which secure the skids
and wear plates (fig. 23).
When tightening loose bolts/nuts the torques listed below
should be applied.
- Convince yourself of the presence and undamaged condi-
tion of all safety decals on the machine (fig. 24).
A
(P/N 9.1170.0408.0) -4x-
B
(P/N 9.1170.0407.6) -2x-
C
(P/N 9.1170.0419.4) -2x-
D
(P/N 9.1170.0410.2) -5x-
E
(P/N 9.1170.0417.2) -3x-
F
(P/N 9.1170.0173.3) -4x-
G
1
(P/N 9.1170.0125.4)
G
2
(P/N 9.1170.0175.5)
H (P/N 16.61.175) -3x-
46
M6 M8 M10 M12 M14 M16 M20 M24
Nm 10 25 50 85 135 215 410 710
kgm 1,0 2,5 5,0 8,5 13,5 21,5 41,0 71,0
A
H
23
24
B
C D
E
F
G
1
G
2
ADF
B
C
D
E
F
G
H
A
C
A
BD
E
F
