LELY SPLENDIMO PC 281 - Change of Grease in Mower Elements

7.6Change of grease in mower
elements
Replace the grease in the mower elements every 500 working
hours or every 1,000 hectares.
Follow the directions listed hereafter.
- Remove the mower disc.
If several bearing housings need to be dismounted, care
should be taken that they are fitted back on the original
mower elements.
- Dismount the bearing housing A (fig. 28) from the element.
Make sure that the shims B remain in place.
- Remove the grease from the element. Do not use a solvent
since it may affect the sealing of the bearings and/or rinse
the grease fill out of the bearings.
Measure the grease quantity carefully. An incorrect
quantity may cause overheating and damage of the
element.
- Fill the elements with 95 grams of grease (Shell Alvania
WR 0).
- Place the bearing housing on the element. Turn the hub (C,
fig. 28) so that it is aligned with the hub of the adjacent
mower element (fig. 29).
- Apply Loctite 243 to the thread of the fillister head screws
and tighten them with a torque of 39 Nm (3,9 kgm).
- Check at the catellated nut the presence of the O-ring D
(fig. 29) in the pressure piece.
- Fit the mower disc. Tighten the castellated nut with a
torque of 150-250 Nm (15-25 kgm) and secure it with a
split pin. Make sure that the split pin does not protrude
above the pressure piece.
48
!
28
39 Nm (3,9 kgm)
0,095 kg
C
A
B
29
150-250 Nm (15-25 kgm)
!
D
