Locatingconnectors,controls,andindicatorsonthefrontofyour
computer
Thefollowingillustrationshowsthelocationsoftheconnectors,controls,andindicatorsonthefrontofyour
computer.
Figure1.Frontconnector,control,andindicatorlocations
1Integratedcameraactivityindicator(availableonsome
models)
2Integratedcamera(availableonsomemodels)
3Integratedmicrophones4Powerindicator
5Internalspeakers
6Cardreaderslot(availableonsomemodels)
7Headsetconnector
8USB3.0connectororAlwaysOnUSBconnector
