Lenovo ThinkCentre E63z - Page 41

Figure4.Locationsofthepartsandconnectorsonthesystemboardon10D4,10D5,10D6,10D7,10EJ,and10EK
models
1LCD-panelconnector2Cameraconnector
3MiniPCIExpresscardslot(WI-FIcardconnector)
4Memoryslot
5Internal-speakerconnector
6Coin-cellbattery
7ClearCMOS/Recoveryjumper8SATAstorage-driveconnector
9Touch-screenconnector
10Control-button-boardconnector
11Converter-boardconnector12Systemfanconnector
Thefollowingfigureshowsthelocationsofthepartsandconnectorsonthesystemboard.
Figure5.Locationsofthepartsandconnectorsonthesystemboardon10E0,10E1,10E2,10E3,10EL,and10EMmodels
1Debugconnector
2Coin-cellbattery
3LCDcableconnector4Cameraconnector
5MiniPCIExpresscardslot(WI-FIcardconnector)
6Memoryslots
7Internal-speakerconnector8Mechanicalunlockconnector
9ClearCMOS/Recoveryjumper10BIOSsocket
Chapter2.Productoverview33
